The OSPRI 3D Fiber Laser Cutting Head is a specialized device used in laser cutting systems to perform precise and dynamic cutting on three-dimensional surfaces.
| Name | 3D fiber laser cutting head |
| Model | LCR03 |
| Interface Type | QBH |
| Wavelength | 1080±10nm |
| Rated Power | ≤4KW |
| Focus Length | 125mm /150mm |
| Collimation Focal Length | 75mm |
| Nozzle Model | Various models and specifications |
| Focusing Range | 12mm~+12mm |
| -9mm~+9mm | |
| Centering Range | ±1.5mm |
| Manual Focus Positioning Accuracy | 0.1mm |
| Follow-up Stroke | 27mm |
| Follow-up Speed | ≤250mm/s |
| Gas ressure | ≤2.5Mpa |
| Weight | 5KG |
